Classic storage tank with double jacket
EV2A 2500 D920 H3750 0/ATM
Material: 137585
Nominal volume in L: 2500
Geometrical volume [l]: 2560
Internal diameter in mm: 920
Height H in mm: 3750
Height Z in mm: 4400
Min. operating press. [barg]: 0
Max. operating pressure [barg]: atmospheric
Min. operating p. DJ [barg]: 0
Max. operating p. DJ [barg]: 3
Min. DJ design p. [barg]: 0
