Classic storage tank with double jacket
EV3A 5000 D1270 H3900 0/ATM
Material: 137746
Nominal volume in L: 5000
Geometrical volume [l]: 5066
Internal diameter in mm: 1270
Height H in mm: 3900
Height Z in mm: 4550
Min. operating press. [barg]: 0
Max. operating pressure [barg]: atmospheric
Min. operating p. DJ [barg]: 0
Max. operating p. DJ [barg]: 3
Min. DJ design p. [barg]: 0
